The New Vector 500 Camo Utility Vehicle brings true powersports performance to a versatile off-road platform. Powered by a 471cc fuel-injected four-stroke engine producing an estimated 20 HP, the Vector 500 can reach a listed maximum forward speed of 45 mph.

Built for hunting, work, and off-road adventures, the Vector 500 Camo features on-demand four-wheel drive with a front differential lock, Hi/Lo range automatic CVT transmission, large 26-inch tires, and shaft-driven 4WD. Its race-inspired Level Flight Suspension system with nitrogen-assisted shocks is designed to provide controlled performance over uneven terrain.

Standard equipment includes a 3,500 lb. winch, removable two-piece windshield, roof, headlights, tail lights, turn signals, mirrors, fender flares, headrests, and front bumper, giving the Vector 500 a comprehensive utility package straight from the factory.

Key Features

471cc Fuel-Injected Engine

The Vector 500 is powered by a 471cc gasoline engine designed to deliver strong off-road performance.

• 471cc fuel-injected four-stroke engine


• Estimated 20 HP


• Maximum listed torque: 16.15 ft-lb


• Gasoline fuel


• 7.6-gallon fuel tank


• OEM-branded engine

Automatic Hi/Lo CVT Transmission

The automatic CVT provides convenient operation while the selectable Hi/Lo range allows the drivetrain to be configured for different riding and utility conditions.

• Automatic CVT transmission


• High/Low range


• Designed for work and off-road applications

On-Demand 4-Wheel Drive

The Vector 500 provides selectable traction through its on-demand 4WD system.

• On-demand 4-wheel drive


• Front differential lock


• Shaft-driven 4WD system


• 10-inch ground clearance

Level Flight Suspension

A race-inspired Level Flight Suspension system combines independent suspension components with nitrogen-assisted shocks to help the vehicle maintain controlled handling over uneven terrain.

• Independent 4-wheel dual A-arm suspension


• Nitrogen-assisted shocks


• Level Flight Suspension system


• 10-inch ground clearance

26-Inch All-Terrain Tires

Large 26-inch tires provide the ground contact needed for outdoor trails, hunting areas, and off-road work.

• 26-inch tires


• Independent 4-wheel suspension


• 10-inch ground clearance

Four-Wheel Hydraulic Disc Brakes

Hydraulic disc brakes on all four wheels provide controlled braking performance for a utility vehicle capable of reaching up to 45 mph.

• 4-wheel hydraulic disc brakes


• Designed for off-road use

Standard Winch & Utility Equipment

The Vector 500 Camo comes equipped with a substantial range of standard accessories.

• 3,500 lb. winch


• Front bumper


• Fender flares


• Mirrors


• Headrests


• Cup holder


• 2-piece removable windshield


• Roof


• On-road light package

Cargo & Towing Capability

The Vector 500 is designed to handle both passengers and utility equipment.

• 2-person seating capacity


• 8.3 cu. ft. cargo bed capacity


• Tilting cargo bed


• 500 lb. load weight capacity


• 3,500 lb. listed towing capacity

Specifications

Engine & Performance

Specification	Details
Engine Displacement	471cc
Engine Type	Fuel-Injected 4-Stroke
Engine Make	OEM Branded Engine
Horsepower	20 HP
Maximum Torque	16.15 ft-lb
Fuel Type	Gasoline
Fuel Tank Capacity	7.6 gal
Maximum Forward Speed	45 mph
Transmission	Automatic CVT
Range	Hi/Lo
Drive System	On-Demand 4-Wheel Drive
Front Differential Lock	Yes
Driveline	Shaft Drive

Suspension, Brakes & Tires

Specification	Details
Suspension	Independent 4-Wheel Dual A-Arm
Shock Type	Nitrogen Assisted
Suspension System	Level Flight Suspension
Brakes	4-Wheel Hydraulic Disc
Tires	26 in.
Ground Clearance	10 in.

Dimensions & Capacity

Specification	Details
Overall Length / Depth	110 in.
Overall Width	61.75 in.
Overall Height	73 in.
Seat Height	34 in.
Wheelbase	76.75 in.
Turning Radius	13 ft
Seating Capacity	2
Cargo Bed Capacity	8.3 cu. ft.
Load Weight Capacity	500 lbs.
Towing Capacity	3,500 lbs.
Product Weight	1,300 lbs.
Fuel Capacity	7.6 gal

Standard Equipment

Equipment	Included
Canopy / Roof	Yes
Windshield	Yes
Removable Windshield	2-Piece
Winch	3,500 lbs.
Headlights	Yes
Tail Lights	Yes
Turn Signals	Yes
Mirrors	Yes
Fender Flares	Yes
Headrests	Yes
Front Bumper	Yes
Cup Holder	Yes
Tilting Cargo Bed	Yes
Cruise Control	No
Tow Hitch Included	No
Assembly Required	No

Utility & Off-Road Applications

The Vector 500 Camo is designed for a variety of outdoor and utility applications, including:

• Hunting


• Off-road adventures


• Trail riding


• Property maintenance


• Outdoor work


• Utility transportation


• Recreational riding

Camo Finish & Outdoor Design

Finished in a Camo color scheme, the Vector 500 is styled for outdoor environments and utility-focused use. The roof, removable windshield, mirrors, fender flares, lighting package, and front bumper provide a practical configuration for extended outdoor operation.

Warranty

The Vector 500 Camo comes with a 2-year manufacturer warranty.

Why Choose the Vector 500 Camo?

The Vector 500 Camo Utility Vehicle combines a 471cc fuel-injected engine, automatic Hi/Lo CVT, on-demand 4WD with front differential lock, independent dual A-arm suspension, nitrogen-assisted shocks, and four-wheel hydraulic disc brakes into a capable off-road platform.

With a 3,500 lb. winch, 3,500 lb. listed towing capacity, tilting cargo bed, 500 lb. load capacity, 7.6-gallon fuel tank, 26-inch tires, roof, removable windshield, and complete lighting package, the Vector 500 is equipped for hunting, work, and recreational off-road use right from the factory.
